The Studiomaster CLUBXS+ series are a range of comprehensive and affordable compact, hard wearing mixing consoles. With all the features required for live mixing or stereo recording an event, duo or band whether at home, in the rehearsal rooms or out at an event.
The compact range is available in 5 to 16 input versions with 19” rack adapters or dedicated 19” rack mounting models to fulful virtually any application.

Specifications:

• Inputs: 10 (6 mic, 2 stereo)

• Gain: Mic 6dB–+50dB, Line +10dB–-34dB

• EIN: -100dB, S/N Ratio: 80dB

• Frequency Response (Mic): 10Hz–20kHz (+1/-3dB), THD: 0.1%

• Max Output: +26dB (balanced) / +20dB (unbalanced)

• Channel EQ: Hi 12kHz, Mid 2.5kHz, Low 45Hz, Lo Cut 80Hz

• Features: MP3/USB/SD playback, USB/SD recording, DSP effects

• Power Supply: 100–240V AC

• Dimensions (W × H × D): 360 × 80 × 365 mm

• Weight: 5 kg
